24
Creating a Patch
Mixing/Modulating Two Sounds (Mod)
The Modulator mixes and modulates the two audio signals.
Selecting a Modulator Type
1
In the lower part of the screen, touch <Mod>.
A screen like the following appears.
fig.Q-32_60
2
In the Modulator Type area, select the modulator type you wish to use.
Applying COSM Modeling to Oscillators
(COSM1/2)
The COSM sections modify the sound in various ways, including filtering the sound.
COSM differs from the Effects section in that while Effects are applied to the final
mix of the sound, COSM is applied individually to each note.
Selecting a COSM Type
1
In the lower part of the screen, touch <COSM1> (or <COSM2>).
Modulator Type Description
MIX Add OSC1 and OSC2.
RING Use OSC2 to apply ring modulation to OSC1.
FM Use OSC2 to apply FM (frequency modulation) to OSC1.
ENV RING Use the envelope of OSC2 to control the volume of OSC1.
OSC SYNC Synchronize the output waveform of OSC1 to the output
waveform of OSC2.
OSC SYNC is valid only when
OSC2 is an analog oscillator.
For more about the modulator
settings, refer to “Mixing/
Modulating Two Sounds
(Mod)” (Owner’s Manual; p.
46).
