d04091
page 7 - 4
Jan. 01/2007
Effectivity: 447 SCDI
OM Edition 1 / Rev. 0
BRP-Rotax
7.4) Engine views:
7.4.1) 447 UL SCDI
PTO view
02781
lateral view
MAG
PTO
PTO ..... power take off side
MAG ..... magneto side
(1) engine number
(2) rewind starter
◆ NOTE: Figure shows fan cooled version with intake silencer.
02782
fig. 1
fig. 2
1
2
