d04091
page 7 - 6
Jan. 01/2007
Effectivity: 582 DCDI
OM Edition 1 / Rev. 0
BRP-Rotax
7.4.3) 582 UL DCDI and 582 UL DCDI mod. 99
(1) engine number
(2) propeller gearbox
(3) Electric starter
◆ NOTE: Figure shows 582 UL DCDI engine with B-gearbox.
02042
02043
MAG
PTO
fig. 6
fig. 5
PTO view
lateral view
1
2
3
