d04091
page 7 - 5
Jan. 01/2007
Effectivity: 503 DCDI
OM Edition 1 / Rev. 0
BRP-Rotax
7.4.2) 503 UL DCDI
PTO view
02780
lateral view
02779
MAG
(1) engine number
(2) propeller gearbox
(3) electric starter
◆ NOTE: Figure shows fan cooled version with intake silencer.
fig. 3
fig. 4
PTO
1
2
3
