setup screen
74_ setup screen
PTZ sequence
1. From the Setup menu, select the <PTZ
( )> tab.
2. Click <PTZ sequence>.
3. Set swing, group, tour, tracing & auto
operation.
To configure the swing settings
Swing is a monitoring function that moves
between two preset points and enables you
to trace the motion.
1. Select <Swing>.
The menu screen will switch to the
swing setting screen.
2. Select a swing setting mode.
• Pan : You can set the swing
monitoring using the PAN function.
• Tilt : You can set the swing
monitoring using the Tilt function.
• Pan&Tilt : You can set the swing monitoring only using both PAN and Tilt
functions.
3. Set <First preset> and <Second preset> to specify a swing range.
J
`
When moving to the second preset from the first preset, the camera will move to the right
direction on the screen.
If you set <Flip/Mirror> to <On> in the video setup, it will move in the opposite direction. (Page 84)
4. Set movement speed and switching time.
5. Press the [
] button.
The first preset, the second preset, speed, and switching time are saved in
accordance with the mode.
6. Press the [
] button.
It performs the swing operation.
7. Press the [
] button.
The running swing will be stop.
J
`
If you want to set the swing, then you need at least two presets set already.
