Sanyo PLC-XF45 Service Manual

-78-
******************************************************
CABINET PARTS
1. 610 283 7070 ASSY,BUTTON-MJ6A
2. 610 301 2919 COMPL HANDLE A-MT8A
3. 610 283 5663 ASSY HINGE- MJ6A
4. 610 301 2940 COMPL LATCH PUSH A-MT8A
6. 610 284 5938 ASSY LATCH PUSH B-MJ6A
7. 610 283 0521 COMPL,STAND LEG A-MJ6A
8. 610 283 7667 COMPL,STAND LEG B-MJ6A
9. 610 284 2876 ASSY,STAND LEG R-MJ6A
11. 645 030 7355 BADGE,SANYO*53.5X12L53.5
12. 610 300 0886 CABINET FRONT-MT8A
13. 610 304 1858 CABINET TOP B-MW8A
14. 610 300 0909 CABINET BOTTOM A-MT8A
16. 610 304 1872 COVER TOP C-MT8A
17. 610 284 2487 COVER LNS A-MJ6A
18. 610 283 5717 DEC INLAY R/C F-MJ6A
19. 610 283 5724 DEC INLAY A-MJ6A
21. 610 283 5731 DEC INLAY B-MJ6A
22. 610 284 0001 DEC INLAY R/C R-MJ6A
23. 610 301 1202 DEC COMP SHEET A-MT8A
24. 610 301 1219 DEC COMP SHEET B-MT8A
26. 610 301 1226 DEC CONT SHEET A-MT8A
27. 610 296 9658 FILTER BASE A-MT8A
28. 610 301 2568 FILTER TOP-MT8A
29. 610 301 4814 NET A-MT8A
31. 610 301 1233 GRILLE SP L-MT8A
32. 610 301 1240 GRILLE SP R-MT8A
33. 610 284 2920 MOUNTING COVER LNS A-MJ6A
34. 610 284 2937 MOUNTING COVER LNS B-MJ6A
36. 610 300 1180 PANEL FRONT TOP-MT8A
37. 610 301 4173 PANEL FRONT BTM-MT8A
38. 610 300 1203 PANEL COMP A-MT8A
39. 610 300 1210 PANEL CONT-MT8A
41. 610 300 8998 PANEL FILTER-MT8A
42. 610 272 9238 SPRING COIL-M6MA
43. 610 285 1366 SPRING COIL-MJ6A
44. 610 289 1829 BADGE V MARK L-ML6A
******************************************************
CHASSIS PARTS
51. 610 303 6984 ASSY,HOLDER LNS A-MT8A
51-A. 645 042 7343 ASSY,MOTOR(ML6A)
51-B. 645 057 3224 SWITCH,SENSOR X
51-C. 645 057 3231 SWITCH,SENSOR Y
51-D. 610 303 9879 ASSY,PWB,LENS NET-BASE
52. 610 303 6717 COMPL,HOLDER POL A-MW8A
53. 610 282 9846 COMPL,HOLDER REL A-MJ6A
54. 610 282 9853 COMPL,HOLDER COND A-MJ6A
55. 610 303 8377 SPACER CONDENSER LENS-MT8A
56. 610 305 5992 COMPL,HOLDER INT A-MW8A
57. 610 303 9572 COMPL,HOLDER PBS A-MT8A
58. 610 295 4876 COMPL,HOLDER POL A-MJ6A
59. 610 302 2437 COVER,MR-MT8A
60. 610 300 0978 COVER,DUCT LMP B-MT8A
61. 610 300 0961 COVER,DUCT LMP A-MT8A
62. 610 300 6574 COVER,DUCT SET A-MT8A
63. 610 283 0613 HOLDER REL D-MJ6A
64. 610 283 0620 HOLDER INT D-MJ6A
65. 610 283 0866 HOLDER PBS D-MJ6A
66. 610 292 2806 HOLDER,MR A-MJ6A
67. 610 283 0668 HOLDER COND D-MJ6A
68. 610 303 9961 MOUNTING PLT B-MW8A
69. 610 293 7282 COVER,PBS A-MJ6A
70. 610 300 1135 HOLDER FILTER PWB A-MT8A
71. 610 300 1128 HOLDER POWER PWB A-MT8A
72. 610 301 5484 HOLDER FILTER PWB-MT8A
73. 610 301 5491 HOLDER SUB PWB-MT8A
74. 610 295 5019 MOUNTING PLT B-MJ6A
75. 610 303 7356 MOUNTING UV FILTER-A-MT8A
76. 610 290 0095 MOUNTING UV FILTER-B-ML6A
77. 610 303 7363 MOUNTING UV FILTER-B-MT8A
78. 610 290 0118 MOUNTING UV FILTER-D-ML6A
79. 610 295 5040 MOUNTING PLT A-MJ6A
80. 610 283 5861 MOUNTING SP A-MJ6A
81. 610 283 5878 MOUNTING SP B-MJ6A
82. 610 284 6065 MOUNTING SP C-MJ6A
83. 610 286 6650 MOUNTING SP D-MJ6A
84. 610 301 6184 SPACER LMP PWB A-MT8A
85. 610 301 5583 OPTICAL BASE TOP-MT8A
******************************************************
86. 610 301 5590 OPTICAL BASE BTM A-MT8A
87. 610 301 5606 OPTICAL BASE BTM B-MT8A
88. 610 301 7976 MOUNTING PLT A-MT8A
93. 610 300 0992 COVER,DUCT LMP D-MT8A
94. 610 300 0985 COVER,DUCT LMP C-MT8A
95. 610 300 0923 COVER,DUCT LCD A-MT8A
96. 610 300 0930 COVER,DUCT LCD B-MT8A
97. 610 300 0947 COVER,DUCT LCD C-MT8A
98. 610 304 2084 COMPL,COVERDUCT LCD D-MT8A
******************************************************
SCREWS
91. 411 180 2904 SCR S-TPG BIN 4X10
92. 411 102 2203 SCR BIN 4X8
******************************************************
OPTICAL PARTS
101. 645 041 2660 ASSY,PRISM(PBS)
102. 645 048 6050 DICHROIC MIRROR (Y/IA)
103. 645 041 2844 DICHROIC MIRROR (C)
104. 645 054 8475 POLARIZATION GLASS(IN/B)
105. 645 054 0356 POLARIZATION GLASS(IN/G)
106. 645 054 0349 POLARIZATION GLASS(IN/R)
107. 645 054 9731 POLARIZATION GLASS(HIN/B)
108. 645 054 9755 POLARIZATION GLASS(HIN/G)
109. 645 041 2837 POLARIZATION GLASS(HIN/R)
110. 645 043 8523 OPTICAL FILTER
111. 645 043 8516 OPTICAL FILTER
112. 645 049 3041 OPTICAL FILTER
113. 645 054 0370 OPTICAL FILTER(UV CUT)
114. 645 047 1858 MIRROR(B-COLD)
115. 645 047 1841 MIRROR(R)
116. 645 041 2745 MIRROR(COLD)
118. 645 054 1278 LENS,CONDENSER(OUT)
119. 645 059 1518 LENS,CONDENSER(IN)
120. 645 041 2875 LENS,RELAY(OUT)
121. 645 041 2868 LENS,RELAY(IN)
122. 645 041 2738 LENS,CONDENSER(G)
123. 645 041 2707 LENS,INTEGRATOR
124. 610 301 8508 ASSY,PRISM/CASE-MW8A
124-1 --- --- ----
124-2 645 054 0363 POLARIZATION GLASS(WV)
124-3 645 051 1400 POLARIZATION GLASS(HOUT/QU)
124-4 645 054 0394 POLARIZATION GLASS(OUT/R)
124-5 645 054 8482 POLARIZATION GLASS(OUT/G)
124-6 645 054 8505 POLARIZATION GLASS(OUT/B)
*******************************************************
129. --- --- ---- Projection lens is optional.
129-A --- --- ----
130. --- --- ---- Depend on the lens
131. --- --- ---- ASSY,CG ADJUSTER LCD-MT8A
(Adjuster is optional)
132. --- --- ---- COMPLE, MOUNTING LENS A-MT8A
132-A --- --- ----
133. --- --- ---- COMPLE, MOUNTING LENS A-IDJK
(Compl, mounting lens is accessory)
********************************************************
Ref. No. Part No. Description
Cabinet and Optical Parts List
Ref. No. Part No. Description
