Enter into sub-menu items or confirm data.
According to the setting of function parameter FE.01, jog or reverse run, and
frequency clearance is available when pressing this key under keypad mode.
Enter into run mode under keypad model.
In common run status the VFD will be stopped according to set mode after
press this key if run command channel is set as keyboard stop effective
mode. The VFD will be reset and resume normal stop status after pressing
this key when the VFD is in malfunction status.
Analog
potentiomet
er knob
Set the frequency; when F0.07=0, digital encoder can set the frequency as
linkage control with increase/decrease key.
Data or function code increase (speed up the increasing rate by keeping
pressing the key)
Data or function code decrease (speed up the decreasing rate by keeping
pressing the key)
3.2 LED and Indicator Light Description：
Table 3-1 LED and Indicator Light Description
Display current run status parameter and set parameter.
