3.3 Monitoring Parameter Display
Keypad display status is classified as power-on initialization display, function code and monitoring parameters display,
malfunction alarm status display, run status parameters display. After power-on, LED will display “P.OFF”, then enter
setting frequency display status.
When the VFD is stopped, the keypad displays stopped state monitoring parameters, factory setting is digital setting
frequency. As is shown in figure 3-2, unit indicator light reminds that the unit of current displayed parameter is Hz.
Press key , different monitoring parameters in stopped state can be displayed circularly (default setting in sequence
is main setting frequency, bus voltage. Other monitoring parameters can be set to display by function code FE.10~FE.11,
for details see function code table FE.10~FE.11); or without pressing , but set tens place of FE.12 as 1 (alternate
display of main and secondary parameters), and the stopped state monitoring parameters will display circularly every
other second automatically; also enter monitoring menu by pressing , and check each monitoring parameter by
, and .
3.4 Run Status Parameter Display
The VFD enters into run status when receiving effective run command and run status monitoring parameters normally
output frequency is displayed on the keypad. As figure 3-2 shows, unit is displayed as Hz.
Press , the current run status parameter will display circularly (default set is output frequency, output current, two
