Schaerer Ltd. Cleaning instructions / 10.2009 / V04
Allmendweg 8 Translated from German
4528 Zuchwil
Switzerland
info@schaerer.com / www.schaerer.com N° 021881
Follow hygiene regulations according to HACCP!
Extract from HACCP:
► Never top up milk container. Always throw leftovers away.
► Always clean the milk container before filling it with fresh milk.
► Fill up with fresh milk, chilled to 3 °C – 5 °C, just before restarting the machine.
► Use pasteurized or ultra hightemperature treated (UHT) milk! Do not use raw milk! The milk must be homogonised!
► If equipped, the refrigerator / cooling unit (optional) must be cleaned at least once a week!
Daily cleaning
Schaerer Coffee Art / Powder doser
7 8
1
2
9
► Clean the steam wand.
10
11
Weekly cleaning:
► Carry out steps
1
to
10
with the weekly
cleaning agent.
Dosage:
Weekpure: 100 ml
Water: 1000 ml
If “Stand by after cleaning” is programmed:
Once cleaning has been completed, the
machine switches to “Stand by”.
Following the use of milk products and subse-
quent cleaning of the milk system, the following
message appears following restart:
remove
rinsing water
► Remove and rinse the cleaning container.
► Con rm using the [
] button.
► Continue with step
7
.
► Remove and wash drip grid under warm,
running water.
► Clean trip tray with a damp paper tissue.
► Place drip grid back.
► Clean external surfaces with a damp paper
tissue.
Do not use any abrasives!
► Pull off the tube from the foamer head.
► Dismantle the foamer head and wash it un-
der warm, running water.
► Remove residues with a brush.
► Mount the foamer head and place it back in.
► Place the tube back onto the foamer head
(don‘t forget the spring!)
Machines without steam:
► Continue with step
10
.
Machines with steam:
► Continue with step
9
.
Wait, until the display shows:
select product
12:00 01.10.2009
► Release the foamer head from the holder
(press the button).
If milk products were dispensed or if the
milk system is deactivated:
The display shows:
milk system
on off
To release milk system:
► Press the [
] button.
To block milk system:
► Press the [
] button.
1
5
3
4
► Press and hold the [ ] button (± 4 sec.).
The display shows:
cleaning program
empty gr. container!
► Pull out the grounds container within 5 sec-
onds and clean it.
► Clean the brew area with the brush.
► Place the grounds container back.
The display shows:
check if mixer
is in place
► Press the button.
Milk Smart:
► Place the hoses in the container
1
. The hose
ends must touch the bottom of the contain-
er!
Milk Smart Cooler:
► Mount the cover and hose
2
.
► Press the [
] button.
Rinsing is running!
(duration: refer to display)
Wait until the display shows:
remove
rinsing water
► Remove and rinse the cleaning container.
► Con rm using the [
] button.
Machines with steam; with activated steam
boiler rinsing:
The display shows:
cleaning program
hot water rinsing
► Place a container under the steam wand.
► Press the [
] button to start the rinsing.
Attention Hot steam!
2
The display shows:
cleaning program
insert tablet
With DECAF cover detection:
► Open DECAF cover.
► Insert one cleaning tablet within 15 seconds.
► Close DECAF cover.
Without DECAF cover detection:
► Insert one cleaning tablet.
► Press the [
] button.
Machines without steam; with deactivated
steam boiler rinsing:
► Continue with step
4
.
6
1 2
1 2
Coffee system & Mixer cleaning is
running! (duration: refer to display)
The display shows:
cleaning programme
cleaning agent
► Fill the cleaning solution into the cleaning
container.
Dosage:
Daypure: 100 ml
Water: 1000 ml
Milk Smart:
► Place the hoses in the container
1
. The hose
ends must touch the bottom of the container!
Milk Smart Cooler:
► Remove and clean the milk container.
► Place the cleaning container in the cooler.
► Mount the cover and hose
2
.
► Press the [
] button.
Cleaning is running!
(duration: refer to display)
Wait until the display shows:
cleaning program
rinsing water
► Rinse the cleaning container and ll it with
1000 ml of fresh water.
If no milk products were dispensed:
► Continue with step
7
.
Refer to the safety instructions and to the chapter “Cleaning”
inside the user manual!
Never reach into the machine or under the beverage outlets
during the automatic cleaning!
