Scheppach DP19Vario Translation Of Original Operating Manual

 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
26
|
GB
The specied vibration value can be used for initial
assessment of a harmful effect.
7. Before commissioning
• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material as well as the
packaging and transport bracing (if available).
• Check that the delivery is complete.
• Check the device and accessory parts for trans-
port damage.
• If possible, store the packaging until the warranty
period has expired.
ATTENTION
The device and the packaging are not children‘s
toys! Do not let children play with plastic bags,
lms or small parts! There is a danger of choking
or suffocating!
8. Installation
Column and machine foot, g. 3
1. Set the machine foot (1) down on the ground or
the workbench.
2. Place the column (2) on the base plate so that the
holes on the column (2) align with the holes on the
base plate (1).
3. Screw the four hexagonal screws (17) to fasten
the column into the base plate and tighten them
using a hexagon spanner.
Removing the rack, Fig.4
In order to install your drill, you must rst remove the
rack (D)
1. Use an Allen key (SW3) to remove the ring (E)
and pull this off the column (2).
2. Now pull the rack (D) out.
Installing the drilling table holder, Fig. 5-/
1. Insert the rack (D) into the groove on the drilling
table holder (4).
2. Align the rack (D) centrally in relation to the drill-
ing table holder (4).
3. When bringing the rack (D) together within the
groove, ensure that the tooth meshing between
the rack and the drilling table holder (4) is cor-
rect.
4. Now place the drilling table holder (4) with the
rack (D) on the column (2) and guide the rack (D)
into the bottom rack guide on the column foot.
5. Use the ring (E) to secure the rack (D). Ensure
that the rack guide on the ring (E) is pointing
downwards. Tighten the integrated Allen screw
to afx the ring (E).
6. Technical Data
Nominal input voltage
230-240V~ 50
Hz
Power rating 550 W
Motor speed 1450 min
-1
Output speed (innitely
adjustable)
440 - 2580 min
-1
Drill chuck mount B16
Chuck 1 - 16 mm
Dimensions of drill table 198 x194 mm
Angle adjustment 45° - 0° - 45°
Drilling depth 60 mm
Pillar diameter 60 mm
Height 830 mm
Weight 27,5 kg
Laser class 2
Wavelength of laser 650mm
Laser output 1mW
Noise and vibration values
The noise levels have been determined in accord-
ance with EN 61029.
sound pressure level - no load L
pA
70.2
dB(A)
sound pressure level - load L
pA
73.5
dB(A)
uncertainty K
pA
3 dB(A)
sound power level - no load L
WA
82.7
dB(A)
sound power level - load L
WA
86.3
dB(A)
uncertainty K
WA
3 dB(A)
Wear hearing protection.
Excessive noise can result in a loss of hearing. Total
vibration values (vector sum of three directions) de-
termined according to EN 61029.
Vibration emission value ah = 1.7 m/s
2
K uncertainty = 1,5 m/s
2
The specied vibration value was established in ac-
cordance with a standardized testing method. It may
change according to how the electric equipment is
used and may exceed the specied value in excep-
tional circumstances.
The specied vibration value can be used to compare
the equipment with other electric power tools.

Scheppach DP19Vario Specifications

General

Drilling	Yes
Chuck type	Keyless
Hammer drilling	No
Adjustable torque	-
Product color	Black, Blue, Red
Idle speed (max)	2580 RPM
Idle speed (min)	440 RPM
Chuck capacity (max)	16 mm
Chuck capacity (min)	1 mm
Drilling diameter in wood (max)	- mm
Input power	550 W

Weight and Dimensions

Depth	730 mm
Width	500 mm
Height	300 mm
Weight	31400 g
