OPERATION
_________________________________________________________________________________________________________
3-2
SIG-QG-17-05 DECEMBER 2017
Version No.: A
3.2 USB OPERATION
The USB port on the front panel of the Display module is used to install software on the Display
module or any of the modules in the GCP unit, as well as downloading logs and reports to a
USB Drive.
3.2.1 USB Drive File Structure
The USB Drive requires that a specific file structure be created on the USB Drive prior to use on
the Display USB port. The GCP system looks for specific file folders to locate, upload, or
download files.
The file structure is as follows:
•SIEMENS
o <DOT#>-<SITE NAME>
 GCP4000
 CONFIGURATIONS
• .PAC FILES
 REPORTS
• <YYYY><MON>
•GCP4000
o APPLICATIONS
 .MCF
 .PAC
o EXECUTIVES
 .MEF
 .TGZ
 .BIN
PAC files or MCFs to be uploaded should be placed under the GCP4000\Applications.
Executive software to be uploaded should be placed under the GCP4000\Executives.
Downloaded files are placed under the Siemens\<DOT#>-<Sitename>\GCP4000 folder.
NOTE
Due to the software commonality, the USB Display device utilizes
folders titled GCP4000 for all GCP models
