Siemens C55 Repair Documentation

V1.20 Page 4 of 48 ICM MP CCQ GRM
A55/C55_Hitachi Company Confidential © Copyright Siemens AG 04/03
1 List of available level 2,5e parts
A55/C55
ID-No Type Board Name, Location Part-No.
D150 VCO HIT Transmitter_VCO L36820-L6097-D670
D1600 VCO IFX Transmitter_VCO L36820-L6109-D670
D171 IC HIT/IFX Egold+ L36810-G6149-D670
D1740 Filter IFX Ant_Switch_Diplexer L36197-F5006-F936
D1785 IC IFX Transceiver IC L36197-F5011-F334
D361 IC HIT/IFX ASIC L36145-J4682-Y43
D800 IC HIT Transceiver IC L36820-L6105-D670
D920 IC HIT PA_Comperator L36820-L6133-D670
R1507 Resistor IFX Temp_Resistor L36120-F4223-H
R959 Resistor HIT Temp_Resistor L36120-F4223-H
V1500 Diode IFX Capa_Diode L36840-D61-D670
V151 Diode HIT/IFX Diode_KB7 L36840-D5062-D670
V181 Diode HIT/IFX Diode_Battery_Interface L36702-A1051
V211 Transistor HIT/IFX Tran._Vibra L36830-C1097-D670
V220 Diode HIT/IFX Diode_Vibra L36851-Z9105-Z981
V222 Transistor HIT/IFX Trans_Light_ L36830-C1112-D670
V223 Transistor HIT Trans_Light_ L36840-C4004-D670
V361 Transistor HIT/IFX Tran._Charge L36830-C1110-D670
V850 Transistor HIT Tran._VCO_Switch L36820-C6047-D670
V920 Diode HIT Feedback_Diode L36840-D5049-D670
V921 Transistor HIT Tran._PA_Switch L36820-C6047-D670
V950 Transistor HIT Tran._26MHz_Ampl. L36840-C4049-D670
V951 Diode HIT Capa_Diode L36840-D61-D670
Z1500 Quartz IFX Oszillator_26MHz L36145-F260-Y17
Z1600 Filter IFX Transmitter_Filter L36145-K280-Y242
Z1700 IC IFX Power_Amplifier L36197-F5005-F487
Z171 Quartz HIT/IFX Quarz/Egold L36145-F102-Y8
Z211 Filter HIT/IFX Logic/IO_Interface L36197-F5000-F116
Z850 VCO HIT 1LO_VCO L36145-G100-Y96
Z851 Filter HIT Filter_BALUN L36145-K260-Y41
Z880 IC HIT Ant_Switch_Diplexer L36145-K280-Y257
Z900 IC HIT Power_Amplifier L36851-Z2002-A59
Z950 Quartz HIT Oszillator_26MHz L36145-F260-Y17
