Connecting MindConnect Elements
5.5 Connecting Port X2 P1 for MindConnect Element
Getting Connected to MindSphere
Getting Started, 05/2018 39
5.5 Connecting Port X2 P1 for MindConnect Element
Objective
The MindConnect Element can now be connected to the plant network or asset.
Requirements
● An asset has been created in Asset Manager.
● The configuration has been transferred via USB stick to the MindConnect Element.
Procedure
To connect the MindConnect Element to your plant network or asset, insert the Ethernet
cable into the port labeled with X2 P1.
The following graphic shows the connecting port of the MindConnect Nano:
Figure 5-8 Connecting Ethernet Port X2 P1 MindConnect Nano
The following graphic shows the connecting port of the MindConnect IoT2040:
Figure 5-9 Connecting Ethernet Port X2 P1 MindConnect IoT2040
