Appendix
A.4 Firewall Settings
Getting Connected to MindSphere
86 Getting Started, 05/2018
Ambient conditions
min. 0 °C
max. 50 °C
Relative humidity
Relative humidity
• Tested according to IEC 60068-2-78
• IEC 60068-2-30: Operation: 5 % to 85 % at 30 °C (no condensation)
• storage / transport: 5 % to 95 % at 25 / 55 °C (no condensation)
Vibrations
Vibration load in operation Tested according to IEC 60068-2-6: 5 Hz to 9 Hz: 3.5 mm; 9 Hz to 200 Hz: 9.8 m/s²
Shock testing
Shock load during operation Tested according to IEC 60068-2-27: 150 m/s², 11 ms
Software
MindConnect Software Pre-installed MindConnect Software
Dimensions
Width 144 mm
Height 90 mm
Depth 53 mm
A.4 Firewall Settings
It is recommended to use a firewall between the Internet and the MindConnect Elements,
this is also recommended for communication to the automation network.
In the direction to Automation Network a firewall supporting NAPT (in case of DMZ, see
section “List of abbreviations”) or supporting the “Ghost-Mode” is required. Siemens offers
many types of Firewalls for fulfilling these requirements.
