Siemens PXC Compact Series User Manual

Hardware Features
36-Point Compact Series Product Diagram
19 |
100
Siemens Industry, Inc.
Technical Reference Manual
145-172
Building Technologies
Restricted
2018-09-25
Hardware Features
CAUTION
Adjacent point connections on the PXC Compact Series share a Common
connection. See the Figure, Common and Sensor Power Connections .
NOTE:
The common for input and output analog points is floating and is not connected to the
common of the 24 Vac input.
Figure 1: Compact 16/24 Shared Ground Connections.

Siemens PXC Compact Series Specifications

General

Brand	Siemens
Model	PXC Compact Series
Category	Control Unit
Language	English
