Siemens SCALANCE XC-100 User Manual

SCALANCE XC-100
Operating Instructions, 06/2016, C79000-G8976-C415-02
11
Description of the device
3
3.1
Product overview
Article numbers
Device
Description
Article number
SCALANCE XC106-2 6 x 10/100 Mbps RJ-45 ports, 2 x 10/100 Mbps SC ports, multi-
mode fiber-optic cable
6GK5 106-2BB00-2AC2
SCALANCE XC108
8 x 10/100 Mbps RJ-45 ports
6GK5 108-0BA00-2AC2
SCALANCE XC116 16 x 10/100 Mbps RJ-45 ports 6GK5 116-0BA00-2AC2
SCALANCE XC124
24 x 10/100 Mbps RJ-45 ports
6GK5 124-0BA00-2AC2
Components of the product
The following components are supplied with a SCALANCE XC-100:
● One IE switch
● A 4-pin terminal block for the power supply (spring-loaded terminal)
● A 2-pin terminal block for the signaling contact (spring-loaded terminal)
Spare parts
The following spare parts are available for SCALANCE XC-100:
Component
Description
Order number
Spring-loaded terminal block, 4
terminals
4-terminal spring-loaded terminal block to connect the pow-
er supply (24 VDC),
for SCALANCE X/W/S/M,
pack of 5
6GK5 980-1DB10-0AA5
Spring-loaded terminal block, 2
terminals
2-terminal spring-loaded terminal block to connect the sig-
naling contact (24 VDC),
for SCALANCE X/W/S/M,
pack of 5
6GK5 980-0BB10-0AA5
