Siemens SCALANCE XC-100 User Manual

SCALANCE XC-100
Operating Instructions, 06/2016, C79000-G8976-C415-02
55
Dimension drawings
9
9.1
SCALANCE XC-100 dimension drawings
Note
Dimensions are specified in mm.
Front view of the SCALANCE XC106-2, SCALANCE XC108
①
Securing bar in the rail mounting position
②
Securing bar in the wall mounting position (as supplied).
Image 9-1 Width and height
