Technical specifications
7
7.1
Technical specifications SCALANCE XC106-2
The following technical specifications apply to the SCALANCE XC106-2.
Technical specifications
Attachment to Industrial Ethernet
Electrical connectors Quantity 6
Connector RJ-45 jack
Properties Half/full duplex, MDI-X pinning
Transmission speed
10 / 100 Mbps
Optical connectors
Quantity
2
Connector
ST(BFOC) socket
Properties
Full duplex acc. to 100Base-FX
Transmission speed
100 Mbps
Cable type
Multimode glass FO cable
Transmitter output (optical)
• Minimum
• Maximum
• -19 dBm
• -14 dBm
Receiver input
• Sensitivity min.
• Input power max.
• -32 dBm
• -3 dBm
Cable cross-section
• 50/125 μm
• 62.5/125 μm
Cable length
• 0 ... 5 km
• 0 ... 5 km
Attenuation
• ≤ 1 dB/km at 1310 nm; 1200 MHz * km
• ≤ 1 dB/km at 1310 nm; 1200 MHz * km
Electrical data
Power supply
Rated voltage
12 to 24 VDC
Voltage range (incl. tolerance) 9.6 to 31.2 VDC Safe Extra Low Voltage
(SELV)
Design
Terminal block, 4 terminals
Properties
Implemented redundantly
Current consumption
At 12 VDC
400 mA
at 24 VDC
200 mA
Effective power loss
4.8 W
Fusing
2.5 A
