Siemens SCALANCE XC-100 User Manual

Technical specifications
7.3 Technical specifications of the SCALANCE XC116
SCALANCE XC-100
Operating Instructions, 06/2016, C79000-G8976-C415-02
43
7.3
Technical specifications of the SCALANCE XC116
The following technical specifications apply to the SCALANCE XC116.
Technical specifications
Attachment to Industrial Ethernet
Electrical connectors
Quantity
16
Connector
RJ-45 jack
Properties
Half/full duplex, MDI-X pinning
Transmission speed
10 / 100 Mbps
Electrical data
Power supply
Rated voltage
12 to 24 VDC
Voltage range (incl. tolerance) 9.6 to 31.2 VDC Safe Extra Low Voltage
(SELV)
Design
Terminal block, 4 terminals
Properties
Implemented redundantly
Current consumption
At 12 VDC
450 mA
at 24 VDC
225 mA
Effective power loss
5.4 W
Fusing
2.5 A
Signaling contact
Quantity
1
Design
Terminal block, 2 terminals
Permitted voltage range
24 VDC
Load capability
max. 100 mA
Permitted ambient conditions
Ambient temperature
During operation up to 2000 m
-40 °C to +70 °C
During storage
-40 ℃ to +85 ℃
During transportation -40 ℃ to +85 ℃
Relative humidity During operation at 25 ℃ ≤ 95 % no condensation
Housing, dimensions and weight
Design
compact
Housing material
Polycarbonate (PC-GF10)
Degree of protection
IP20
Dimensions (W x H x D)
120 x 147 x 125 mm
Weight
775 g
Installation options
• Wall mounting
• Installation on a DIN rail
• Mounting on an S7-300 standard rail
• Mounting on an S7-1500 standard rail
Mean time between failure (MTBF)
MTBF (EN/IEC 61709; 40 °C)
> 73.69 years
