PP7, PP17-I, PP17-II Equipment Manual
Release 06/98
Unit Description PP7
 
 
204
144
128
30
4
108
55
188
The PP7 requires a mounting cut-out of 130 mm x 190 mm (W x H).
Note
The installation depth of the Push Button Panel is dependent on the type of
connection cable to the PLC. It does not correspond to the outer dimensions of
the unit. Ensure the cable has a suf ficient bending radius.
Unit dimensions
Mounting cut-out
5
