A-2
PP7,
PP17-I, PP17-II Equipment Manual
Release 06/98
PP17-IIPP17-IPP7Ambient conditions
Shock loading
Operation
Shipping, storage
15 g/11 msec
25 g/6 msec
Vibration
Operation
Shipping, storage
0.075 mm (10 Hz ... 58 Hz)
1 g (58 Hz ... 500 Hz)
3.5 mm (5 Hz ... 10 Hz)
1 g (10 Hz ... 500 Hz)
Max. pressure difference (front/rear sides) 2hPa
Barometric pressure
Operation
Shipping, storage
706 to1030 hPa
581 to 1030 hPa
The
conformity of the product described with the regulations of Directive 89/336 EEC is proved by com
-
pliance with the following standards:
Interference immunity EN 50082-1 PP7 PP17-II PP17-II
Static discharge (contact discharge) EN 61000-4-2 Class 3
RF irradiation EN 61000-4-3 Class 3
Pulse modulation ENV 50204 (900 MHz "5 MHz)
RF conduction ENV 50141 Class 3
Burst interference ENV 61000-4-4 Class 3
Radio interference EN 50081-2 PP7 PP17-I PP17-II
RFI suppression EN 55011 Class A
A.2 Digital inputs and outputs
24 V digital inputs PP7 PP17-I PP17-II
Power supply
Rated value
Permissible range
Value
at t < 0.5 s
+ 24 V DC
+18.0 ... +30.0 V
35 V
Connectable Keys, switches
Number of inputs 4 16
Potential isolation from internal circuitry -
