Siemens SIMATIC PP7 User Manual

7-1
PP7, PP17-I, PP17-II Equipment Manual
Release 06/98
Unit Description PP17-II
  
204
240
224
4
99
53
32
188
The PP17-II requires a mounting cut-out of 226 mm x 190 mm (W x H).
Note
The installation depth of the Push Button Panel is dependent on the type of
connection cable to the PLC. It does not correspond to the outer dimensions of
the unit. Ensure the cable has a suf ficient bending radius.
Unit dimensions
Mounting cut-out
7
