A-1
PP7,
PP17-I, PP17-II Equipment Manual
Release 06/98
Technical Data
A.1 General
technical data
Housing PP7 PP17-I PP17-II
External dimensions W x H x D (mm) 240 x 144 x 53 204 x 240 x 53
Mounting cut-out W x H (mm) 130 x 190 226 x 190
Mounting depth (mm)
without bus connector
with angled bus connector
Order no.: GES 7972 - 0BB10-0 x 70
with non-angled bus connector
Order no.: GGK 1500 - 0EA00
53
75
130
Degree of protection
Front panel
Rear panel
IP65
IP20
Weight approx. (kg) 0.72 1.13
24 V voltage supply PP7 PP17-I PP17-II
Rated voltage (VDC) +24
Permissible range (VDC) +18 to +30
Typical power consumption at 24 V with
no load applied at digital outputs
0.2 A 0.4 A
Starting current inrush I
2
t 30x10
–3
A
2
s
Fuse type, internal Electronic fuse
Reverse battery protection Yes
Ambient conditions PP7 PP17-I PP17-II
Ambient temperature
In operation
Shipping, storage
0 to 55 C
-20 ... 70 C
Relative humidity
Operation
Shipping, storage
95%, no condensation
95%
