Spare Parts 08.96
7-4 Siemens AG 6SE7087-6BM70
SIMOVERT MASTER DRIVES Operating Instructions
Part code No. Designation Order number No. Used in
ACCESSORIES Connector set,
SIMOVERT VC
6SY7000-0AC13 1 6SE7035-1TJ20
6SE7036-0TK20
6SE7037-0TK20
6SE7038-6TK20
6SE7041-1TM20
6SE7041-3TM20
ACCESSORIES Connector set,
SIMOVERT VC
6SY7000-0AC50 1 6SE7041-1TK20
Table 7.1 Spare parts
7.2 Converter 675 V to 780 V DC
Part code No. Designation Order No. No. Used in
+A10 -U1 (-A100, -A101, -A110, -A111, -A200, -A201,
-A210, -A211, -A300, -A301, -A310, -A311)
+A12 -U1 (-A100, -A101, -A110, -A111, -A200, -A201,
-A210, -A211, -A300, -A301, -A310, -A311)
IGBT transistor module 6SY7000-0AB71 24 6SE7041-0UM20
6SE7041-1UM20
+A10 -U1 (-A100, -A101, -A110, -A111, -A200, -A201,
-A210, -A211, -A300, -A301, -A310, -A311)
+A12 -U1 (-A100, -A101, -A110, -A111, -A200, -A201, -
A210, -A211, -A300, -A301, -A310, -A311)
IGBT transistor module 6SY7000-0AC36 24 6SE7041-2UM20
+A10 -U1 (-A100, -A101, -A110, -A111, -A200, -A201,
-A210, -A211, -A300, -A301, -A310, -A311)
+A12 -U1 (-A100, -A101, -A110, -A111, -A200, -A201,
-A210, -A211, -A300, -A301, -A310, -A311)
IGBT transistor module 6SY7000-0AC37 24 6SE7041-4UM20
6SE7041-6UM20
+A10 -U1 (-A118, -A119, -A218, -A219, -A318, -A319),
+A12 -U1 (-A118, -A119, -A218, -A219, -A318, -A319)
SML3 inverter snubber
board
6SE7038-6GK84-
1GG0
12 6SE7041-0UM20
6SE7041-1UM20
6SE7041-2UM20
6SE7041-4UM20
6SE7041-6UM20
+A10 -U1 (-A19, -A29, -A39),
+A12 -U1 (-A19, -A29, -A39)
IGD8 inverter gating
board
6SE7035-7GK84-1JC0 6 6SE7041-0UM20
6SE7041-1UM20
+A10 -U1 (-A19, -A29, -A39),
+A12 -U1 (-A19, -A29, -A39)
IGD8 inverter gating
board
6SE7038-6GK84-1JC0 6 6SE7041-2UM20
6SE7041-6UM20
+A10 -U1 (-A19, -A29, -A39),
+A12 -U1 (-A19, -A29, -A39)
IGD8 inverter gating
board
6SE7036-5GK84-1JC0 6 6SE7041-4UM20
+A10 -U1 (-C110, -C120),
+A12 -U1 (-C110, -C120)
MKP capacitor for the
fan
6SY7000-0AB64 4 6SE7041-0UM20
6SE7041-1UM20
+A10 -U1 (-C110, -C120),
+A12 -U1 (-C110, -C120)
MKP capacitor for the
fan
6SY7000-0AC35 4 6SE7041-2UM20
+A10 -U1 (-C110, -C120),
+A12 -U1 (-C110, -C120)
MKP capacitor for the
fan
6SY7000-0AC38 4 6SE7041-4UM20
6SE7041-6UM20
6SE7038-6UK20
+A10 -U1 (-E1, -E2),
+A12 -U1 (-E1, -E2)
Nozzle for radial fan 6SY7000-0AB65 4 6SE7041-0UM20
+A10 -U1 (-E1, -E2),
+A12 -U1 (-E1, -E2)
Radial fan 6SY7000-0AB68 4 6SE7041-0UM20
6SE7041-1UM20
6SE7041-2UM20
+A10 -U1 (-E1, -E2),
+A12 -U1 (-E1, -E2)
Nozzle for radial fan 6SY7000-0AB65 4 6SE7041-1UM20
