08.96 Spare Parts
Siemens AG 6SE7087-6BM70
7-9
SIMOVERT MASTER DRIVES Operating Instructions
Part code No. Designation Order No. No. Used in
-R28 VDU resistor 6SY7000-0AC33 1 6SE7033-0UJ20
6SE7033-5UJ20
6SE7034-5UK20
6SE7035-7UK20
6SE7036-5UK20
6SE7038-6UK20
OPTION L31: +A10 -U1 (-F41, -F42, -F43, -F44),
+A12 -U1 (-F41, -F42, -F43, -F44)
Fuse insert 6SY7000-0AC16 8 6SE7041-0UM20
6SE7041-1UM20
6SE7041-2UM20
OPTION L31: +A10 -U1 (-F41, -F42, -F43, -F44),
+A12 -U1 (-F41, -F42, -F43, -F44)
Fuse insert 6SY7000-0AC20 8 6SE7041-4UM20
6SE7041-6UM20
OPTION L31: -F41, -F42 Fuse insert 6SY7000-0AC17 2 6SE7033-0UJ20
6SE7033-5UJ20
6SE7034-5UK20
OPTION L31: -F41, -F42, -F43, -F44 Fuse insert 6SY7000-0AC16 4 6SE7035-7UK20
6SE7036-5UK20
OPTION L31: -F41, -F42, -F43, -F44 Fuse insert 6SY7000-0AC20 4 6SE7038-6UK20
ACCESSORIES Connector set,
SIMOVERT VC
6SY7000-0AC13 1 6SE7033-0UJ20
6SE7033-5UJ20
6SE7034-5UK20
6SE7035-7UK20
6SE7036-5UK20
6SE7038-6UK20
6SE7041-0UM20
6SE7041-1UM20
6SE7041-2UM20
6SE7041-4UM20
6SE7041-6UM20
7.3 Converter 890 V to 930 V DC
Part code No. Designation Order No. No. Used in
+A10 -U1 (-A100, -A101, -A110, -A111, -A200, -A201,
-A210, -A211, -A300, -A301, -A310, -A311)
+A12 -U1 (-A100, -A101, -A110, -A111, -A200, -A201,
-A210, -A211, -A300, -A301, -A310, -A311)
IGBT transistor module 6SY7000-0AB71 24 6SE7041-0WM20
6SE7041-1WM20
+A10 -U1 (-A100, -A101, -A110, -A111, -A200, -A201, -
A210, -A211, -A300, -A301, -A310, -A311)
+A12 -U1 (-A100, -A101, -A110, -A111, -A200, -A201,
-A210, -A211, -A300, -A301, -A310, -A311)
IGBT transistor module 6SY7000-0AC36 24 6SE7041-2WM20
+A10 -U1 (-A100, -A101, -A110, -A111, -A200, -A201,
-A210, -A211, -A300, -A301, -A310, -A311)
+A12 -U1 (-A100, -A101, -A110, -A111, -A200, -A201, -
A210, -A211, -A300, -A301, -A310, -A311)
IGBT transistor module 6SY7000-0AC37 24 6SE7041-4WM20
6SE7041-6WM20
+A10 -U1 (-A108, -A109, -A208, -A209, -A308, -A309),
+A12 -U1 (-A108, -A109, -A208, -A209, -A308, -A309)
SMU3 inverter snubber
board
6SE7038-6GK84-1GF0 12 6SE7041-6WM20
+A10 -U1 (-A118, -A119, -A218, -A219, -A318, -A319),
+A12 -U1 (-A118, -A119, -A218, -A219, -A318, -A319)
SML3 inverter snubber
board
6SE7038-6GK84-
1GG0
12 6SE7041-0WM20
6SE7041-1WM20
6SE7041-2WM20
6SE7041-4WM20
6SE7041-6WM20
+A10 -U1 (-A19, -A29, -A39),
+A12 -U1 (-A19, -A29, -A39)
IGD8 inverter gating
board
6SE7035-7GK84-1JC0 6 6SE7041-0WM20
6SE7041-1WM20
+A10 -U1 (-A19, -A29, -A39),
+A12 -U1 (-A19, -A29, -A39)
IGD8 inverter gating
board
6SE7038-6GK84-1JC0 6 6SE7041-2WM20
6SE7041-6WM20
