Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
173
Machine data
2.3 Channel-specific machine data
Description: Parameterization of the "basic blocks with absolute values" function
Bit 0 = 1 :
The position values of the transverse axis are always displayed as diameter
values.
Transverse axes can be applied using MD20100 $MC_DIAMETER_AX_DEF or MD30460
$MA_BASE_FUNCTION_MASK, bit 2.
Description: A version information freely available to the user
(is indicated in the version screen)
Description: This machine data can be used for stating the technology independently of the
channel.
This information is used, among other things, for evaluating HMI, PLC and
standard cycles.
Meaning:
MD = 0:Milling
MD = 1:Turning
MD = 2:Grinding
21:Cylindrical grinding
22:Surface grinding
MD = 3:Nibbling
MD = 4:...
(Enter additional technologies as and when required.)
27100 ABSBLOCK_FUNCTION_MASK N01 K1,P1
- Parameterize basic blocks with absolute values DWORD PowerOn
-
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x1 2/2
27400 OEM_CHAN_INFO A01, A11 -
- OEM version information STRING PowerOn
-
- 3 , , , , , , , , ... - - 2/2
27800 TECHNOLOGY_MODE C09 A2,K1
- Mode of technology in channel BYTE NEW CONF
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 - 1/0
808d-me62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 - 1/0
808d-te42 - 1 0 - 1/0
808d-te62 - 1 0 - 1/0
