SIPART DR19
C73000-M7474-C34-4
27
3 Scope of supply and main specifications
D 1 controller as ordered
D 1 inlet connector for non-heating apparatus
D 2 plug-in locating devices
D 1 assembly and instruction manual
D 1 ”Operating and configuring” quick reference
D 2 adhesive labels ”Aux. power 115 V”
Order No. Controller type Power supply
6DR1900-4 S/K controller 24 V~/=
6DR1900-5 S/K controller 230 V~/115 V~
Signal converter modules have separate order and delivery codes.
Mounting position any
Climatic category 3k3 DIN/IEC 721 T3-3
Permissible ambient
temperature during operation 0 to +50 °C
Protection type EN 60529
Front panel unit IP64
Housing/Terminals IP30 / IP20
see chapter 5
Rated voltage AC (selectable) 11 5 V~ / 230V~ 15%,
47 to 63 Hz
Max. power 15 W/19 VA
Rated v oltage UC 24V
=
/~
DC 20 to 28 V
AC 24 V15%;47to63Hz
Max. power 12 W/17 VA
Serial connection
22 nF/220 Ω in parallel to a varistor 420 V
eff
For further specifications, refer to the catalog MP31 and the manual
C73000-B7476-C142.
Equipment
Basic unit
Signal
converter
General
Dimensions
Power supply
Spark sup -
presser unit
