2.22 Additional Functions
327
7UT613/63x Manual
C53000-G1176-C160-2
2.22.8.4 Information List
2.22.9 Commissioning Aids
For commissioning of the device, a comprehensive commissioning and monitoring
tool is available.
2.22.9.1 Web Monitor
The device is provided with a comprehensive commissioning and monitoring tool that
monitors and checks the measured values and the whole differential protection
system. Using a personal computer in conjunction with a web browser, this tool
enables the user to clearly chart the state of the system and the differential protection
values, measured values and indications. The necessary operator software is integrat-
ed in the device; online help can be found on the DIGSI CD and is also available in the
Internet.
To ensure a proper communication between the device and the PC browser the trans-
mission speed must be equal for both. Furthermore, an IP-address is necessary so
that the browser can identify the device. For 7UT613/63x, the following is valid:
The „Web Monitor“ shows the device front with its keypad and LCD display on the
screen, thus allowing to operate the device from the PC. The actual operation of the
device can be simulated with the mouse pointer.
Measured values and the values derived from them are graphically dis-
played as phasor diagrams. You can also view tripping diagrams, scalar values are
shown in numerical form. Most of the measured values discussed in Subsection
2.22.2 can also be displayed in the „Web Monitor“.
For more details on working with the „Web Monitor“, refer to the Online Help attached.
Function
Description
This tool allows to graphically illustrates on a PC, for example, the currents and their
phase angles for both sides of the protected object during commissioning and during
operation. In addition to phasor diagrams of measured values, numerical values are
indicated. The following figure shows an example of this function.
Additionally the position of the differential and restraint values can be viewed in the
tripping characteristic.
No. Information Type of In-
formation
Comments
- FltRecSta IntSP Fault Recording Start
4 >Trig.Wave.Cap. SP >Trigger Waveform Capture
30053 Fault rec. run. OUT Fault recording is running
Transmission speed: 115 kBaud;
IP-address
for connection at the front operator interface: 192.168.1.1,
for connection to the rear service interface (port C): 192.168.2.1.
