A.8 Settings
Addresses which have an appended "A" can only be changed with DIGSI, under Ad-
ditional Settings.
The table indicates region-specific presettings. Column C (configuration) indicates the
corresponding secondary nominal current of the current transformer.
Addr. Parameter Function C Setting Options Default Setting Comments
0 MEAS. QUANTITY Flx I-Meas Loc/side
Curr. I1..I12
Curr. IZ1..IZ4
Voltage
P forward
P reverse
Q forward
Q reverse
Power factor
Frequency
I-Meas Loc/side Selection of Measured Quantity
0 Func. assigned Flx Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 Function is applied to
0 Func. per phase Flx IL1..IL3
IL1
IL2
IL3
3I0 (Zero seq.)
I1 (Pos. seq.)
I2 (Neg. seq.)
IL1..IL3 Function utilises component(s)
0 Func. assigned Flx I-CT 1
I-CT 2
I-CT 3
I-CT 4
I-CT 5
I-CT 6
I-CT 7
I-CT 8
I-CT 9
I-CT 10
I-CT 11
I-CT 12
I-CT 1 Function is applied to
0 Func. assigned Flx AuxiliaryCT IX1
AuxiliaryCT IX2
AuxiliaryCT IX3
AuxiliaryCT IX4
AuxiliaryCT IX1 Function is applied to
0 Func. per phase Flx UL1E..UL3E
UL1E
UL2E
UL3E
UL12..UL31
UL12
UL23
UL31
U0 (Zero seq.)
U1 (Pos. seq.)
U2 (Neg. seq.)
U4/Uen
UL1E..UL3E Function utilises component(s)
0 PICKUP WITH Flx Exceeding
Dropping below
Exceeding Pickup with
0A Type of meas. Flx accurate
fast
accurate Selection of type of measure-
ment
0 FLEXIBLE FUNC. Flx OFF
ON
Alarm Only
Block relay
OFF Flexible Function
