Siemens SIRIUS User Manual

Product description
3.2 Device versions
SIRIUS - SIRIUS 3RA load feeders
Manual, 09/2016, A5E03656507520A/RS-AB/003
21
Reference
More information ...
Can be found in the chapter titled ...
About assembly kits for fuseless load feeders
Accessories (Page 125)
Connection systems
Self-assembled fuseless load feeders are available with the following connection system
options.
Table 3- 5 Connection systems available for self-assembled fuseless load feeders
Connection system
Self-assembled fuseless load feeders
S00 / S0
S2
S3
Screw terminals
✓
✓
✓
Spring-loaded connection
✓
2) 2)
Ring cable lug connection
✓
1)
—
—
1)
These versions can be snapped onto a DIN rail. Mounting on a busbar adapter is not possible.
2)
In the case of size S2 and S3 devices, spring-loaded terminals are only possible in the auxiliary circuit.
Rated powers
The pre-assembled feeders are dimensioned for the following powers:
Assembly
S00
S0
S2
S3
Direct-on-line starter
with link module 7.5 kW (14 A) at
T
a
60 °C
1)
7.5 kW (16 A) at
T
a
40 °C
1)
15 kW (29 A) at
T
a
60 °C
1)
15 kW (32 A) at
T
a
40 °C
1)
37 kW (65 A) at
T
a
60 °C
1)
45 kW (87 A) at
T
a
60 °C
1)
55 kW (100 A) at
T
a
40 °C
1)
Separately wired
7.5 kW (16 A)
18.5 kW (38 A)
37 kW (80 A)
55 kW (100 A)
Reversing starter
with link module 7.5 kW (14 A) at
T
a
60 °C
1)
7.5 kW (16 A) at
T
a
40 °C
1)
15 kW (29 A) at
T
a
60 °C
1)
15 kW (32 A) at
T
a
40 °C
1)
37 kW (65 A) at
T
a
60 °C
1)
45 kW (87 A) at
T
a
60 °C
1)
55 kW (100 A) at
T
a
40 °C
1)
Separately wired
7.5 kW (16 A)
18.5 kW (38 A)
37 kW (80 A)
55 kW (100 A)
1)
Observe the installation guidelines (Page 36) when installing a load feeder with a link
module.
Control supply voltages of load feeders
The contactors can be ordered with different rated control supply voltages as appropriate for
the application area of the fuseless load feeders.
