P100 = control type
Parameter description P100 = 0
V/f + n
P100 = 1
V/f
P100 = 2
Textile
f-Reg.
(P587 = 0)
n-Reg.
(P587 = 0)
P100 = 5
T-Reg.
P038.1 DispTorqConn.r39.1 - - - - - Sw-KP
P038.1 DispTorqConn.r39.2 - - - - - K0165
P040.1 DispSpdConn.r41.1 Setp CP Setp CP Setp CP Setp CP Setp CP KK0150
P040.2 DispSpdConn.r41.2 KK0148 KK0148 KK0148 KK0148 KK0148 KK0148
P040.3 Disp Freq Conn.r41.3 - - - KK0091 KK0091 KK0091
P042.1 Disp Freq Conn.r43.1 Setp CP Setp CP Setp CP Setp CP Setp CP KK0150
P042.2 Disp Freq Conn.r43.2 KK0148 KK0148 KK0148 KK0148 KK0148 KK0148
P042.3 Disp Freq Conn.r43.3 KK0199 KK0199 KK0199 KK0091 KK0091 KK0091
9.2.2 Parameterizing with user settings
During parameterization by selecting user-specific fixed settings, the
parameters of the unit are described with values which are permanently
stored in the software. In this manner, it is possible to carry out the
complete parameterization of the units in one step just by setting a few
parameters.
The user-specific fixed settings are not contained in the standard
firmware; they have to be compiled specifically for the customer.
If you are interested in the provision and implementation of fixed
settings tailored to your own requirements, please get in contact with
your nearest SIEMENS branch office.
P366 = ?
P970 = 0
Start parameter reset
0: Parameter reset
1: No parameter change
Select desired factory setting
0...4: Factory settings
5: User setting 1 (currently as P366 = 0)
6: User setting 2 (currently as P366 = 0)
:
10: Lift and lifting equipment
P060 = 2 Select "Fixed settings" menu
Unit carries out parameter
reset and then leaves the
"Fixed settings" menu
Fig. 9-3 Sequence for parameterizing with user settings
