Singer H74 User Manual

10
Bobbin winding
WINDING THE BOBBIN
Place the thread and spool holder onto the spool pin.
For larger spools of thread, place the large side of the
spool holder toward the spool. For smaller spools of
thread, place the small side of the spool holder toward
the spool, or use the small spool holder. If the thread
spool has a thread retaining slit, place this end of the
spool toward the right, so the thread doesn't get caught
while winding the bobbin.
1
1
Snap the thread into the thread guide.
2
2
Place the thread end through one of the inner holes in
the bobbin as illustrated and place empty bobbin on
the spindle.
4
4
Push the bobbin to right.
5
5
Wind the thread counter-clockwise around the bobbin
winder tension disks.
3
3
4
1
3
2
10
4
1
3
2
10

Singer H74 Specifications

General

Brand	Singer
Model	H74
Category	Sewing Machine
Language	English
