Singer H74 - Walking Foot; Walking Foot Attachment and Use

Please Note: Always try to sew first
without the walking foot accessory which
should be used only when necessary.
It is easier to guide the fabric and you have a
better view of the seam when using the
standard, regular foot on your machine. Your
sewing machine offers excellent stitch quality
on a wide range of fabrics from delicate
chiffons to multiple layers of denim.
The Walking foot attachment equalizes the
feeding of the fabric layers. It improves the
matching of plaids, stripes and patterns. It
also helps to prevent uneven feeding of
difficult or napped fabrics, such as velvet or
corduroy.
1 Lift the presser foot lifter to raise the
presser foot bar.
2 Remove the presser foot holder by
unscrewing (counterclockwise) the presser
bar attaching screw.
3 Attach the Walking foot to the machine as
follows:
- The arm (a) should fit into above the
needle screw and clamp (b).
- Slide the attaching head (c) from left to
right, so that it is fitted onto the presser
foot bar.
- Lower the presser foot bar.
- Replace and tighten (clockwise) the
presser bar attaching screw.
- Make sure both the needle screw and the
presser bar attaching screw are tightly
secured.
4 Draw the bobbin thread up and place both
the bobbin thread and the needle thread
behind the walking foot attachment.
2
3
4
1
1
WALKING FOOT
* The Walking foot is an optional accessory.
57
c
a
b
4
2
3
1
