Net partition
Fig. 105 Using the net partition behind the rear seats
Read and observe and on page 98 first.
The net partition can either be installed behind the rear seats or behind the
front seats.
Install behind the rear seats
›
Remove the boot cover » page 101, Luggage compartment cover.
›
Remove the net partition from the bag.
›
Unfold both parts of the cross rod until they are heard to engage.
›
First insert the rod into the mount
B
» Fig. 105 on one side and push it for-
wards. In the same way, insert the cross rod into the mount
B
on the other
side of the vehicle.
›
Hang the carabines
C
at the ends of the strap into the lashing eyes behind
the rear seats.
›
Pull the belts through the tensioning clasp.
Remove from behind the rear seats
›
Undo the belts on both sides and unhook the carabiners
C
» Fig. 105.
›
Push the cross rod first of all on the one side and then on the other side to-
wards the rear.
›
Remove the cross rod from the mounts
B
.
Merge
›
Press the red button on hinge
A
» Fig. 105 - the hinge breaks.
›
Put the net partition folded together in the bag and close it.
›
Attach the bag with the aid of the plastic carabines to the eyes on the left
and right boot trim panel.
Installing and removing the net partition behind the rear seats with variable
loading floor is carried out in the same way as behind the rear seats without
variable loading floor. Use the lower fixing eyelets on the carrier rails in order
to attach the carabines.
Installing and removing the net partition behind the rear seats is carried out
in the same way as behind the rear seats. Use the fixing eyelets on the rear of
the front seats to attach the carabines. To enlarge the boot, the rear seats can
be removed » page 84.
The opening
D
» Fig. 105 in the net partition is designed to pass the three-
point seat belt » page 13 through.
Storage compartments
Fig. 106 Storage compartment on the left / right
Read and observe and on page 98 first.
The cover for the storage compartment
A
» Fig. 106 can be removed, thus en-
larging the boot.
›
Grasp the top part of the cover
A
and carefully remove it in the direction of
the arrow.
CAUTION
■
The removable storage compartment
A
» Fig. 106 on the left side is suitable
for stowing small objects weighing up to 1.5 kg.
■
The storage compartment
B
is designed for storing small objects of up to
0.5 kg. in weight in total.
102
Using the system
