Skoda Yeti 2015 User Manual

Hitch and trailer
Hitch

Introduction
This chapter contains information on the following subjects:
Description 143
Adjusting the ready position 144
Correctly set ready position 144
Installing the ball rod 145
Check proper fitting 145
Removing the ball rod 146
Accessories 147
The maximum trailer drawbar load is 80 kg/h.
On vehicles with four-wheel drive and the 2.0 l / 103 kW TDI CR or 2.0 L /
110 kW TDI CR engine, the maximum trailer nose weight is 85 kg .
WARNING
■
Check that the tow bar is seated correctly and is secured in the mounting
recess before the start of every journey.
■
Do not use the ball head, if it is not correctly inserted into the mounting
recess and secured.
■
Do not use the towing equipment if it is damaged or incomplete.
■
Do not modify or adapt the towing device in any way.
■
Never release the tow bar while the trailer is still coupled.
■
Keep the mounting recess of the towing equipment clean at all times.
Such dirt prevents the ball head from being attached securely.
CAUTION
■
Take care with the ball bar - risk of paint damage to the bumper.
■
Always attach the cap to the receiving shaft when the ball bar is removed -
risk of receiving-shaft contamination.
Note
■
Operation and maintenance of towing equipment » page 158.
■
The towing vehicle by means of the detachable ball rod » page 193.
Description
Fig. 144 Carrier for the towing device/tow bar
Read and observe
and on page 143 first.
The ball head can be removed and is kept in the spare wheel well or in a com-
partment for the spare wheel in the luggage compartment.
Support for the Towing hitch and tow bar » Fig. 144
13-pin power socket
Mounting recess
Safety eyelet
Cover for the mounting recess
Dust cap
Locking ball
Green marking on the handwheel
Handwheel
Key
Lock cap
Red marking on the handwheel
Green box on the tow bar
Tow ball
Note
On the bottom of the key is a code number. We advise you to write it down. If
you lose a key, please contact a specialist garage, who will be able to use this
code number to provide you with a new one.

1
2
3
4
5
6
7
8
9
10
11
12
13
143
Hitch and trailer
