Attaching the windscreen wiper blade
›
Push the windscreen wiper blade to the stop until it locks into place.
›
Check that the windscreen wiper blade is correctly attached.
›
Fold the wiper arm back to the windscreen.
Fuses and light bulbs
Fuses
Introduction
This chapter contains information on the following subjects:
Fuses in the dash panel 199
Assignment of the fuses in the dash panel 199
Fuses in the engine compartment 200
Assignment of fuses in the engine compartment 201
Individual electrical circuits are protected by fuses.
Switch off the ignition and the corresponding power consuming device before
replacing a fuse.
Find out which fuse belongs to the component that is not operating
» page 199, Fuses in the dash panel or » page 200, Fuses in the engine com-
partment.
Fuse colour Maximum amperage
light brown 5
dark brown 7.5
red 10
blue 15
yellow 20
white 25
green 30
orange 40
red 50
WARNING
Always read and observe the warnings before completing any work in the
engine compartment » page 165.
198
Do-it-yourself
