Slayer Professional Series User Manual

1. Press and release the jog wheel above the left grouphead to
activate the main menu.
2. Rotate the jog wheel clockwise until the “Hot Water Dose”
setting appears.
3. Press and release the jog wheel to enter the “Hot Water
Dose” setting. The “on” button, found directly next to the
hot water tap, will begin to flash.
4. Rotate the jog wheel to adjust the hot water dose in tenth-
second (0.5-second) increments: clockwise rotations
increase the hot water dose; counter-clockwise rotations
decrease the hot water dose.
5. Press and release the jog wheel to confirm your new setting
and return to the menu, or press and hold the jog wheel to
confirm your new setting and exit the menu.
Alternatively, after completing steps 1-3, you may skip
to the “Alternative Procedure”, below.
ALTERNATIVE PROCEDURE
1. Complete “Adjust Hot Water Dose” steps 1-3, above.
2. Press and release the “on” button to dispense hot water.
The Barista Dashboard will begin a timer to display and
record the duration of the dose.
3. Press and release the “on” button again to stop the flow of
hot water. The duration of the dose will be recorded.
The hot water dose may not exceed 20 seconds.
4. Press and release the jog wheel to confirm your new setting
and return to the menu, or press and hold the jog wheel to
confirm your new setting and exit the menu.
• Flat Blade Screwdriver
PROCEDURE
1. Remove the cups and tray. You will NOT need to remove
the back or side panels to make this adjustment.
2. Locate the blending valve between the Vaporizer and the
Proportional valve.[see attached photo]
3. Adjust the hot water temperature from the rear right side of
the machine (guest expereince side): clockwise rotations
increase the hot water temperature; counter-clockwise
rotations decrease the hot water temperature.
4. Verify the temperature at the hot water tap with a digital
thermometer.
ADJUST HOT WATER DOSE
Slayer Steam X utilizes a timer to dispense pre-configured
volumes of hot water. Adjust the hot water dose with the
following steps.
PROCEDURE
ADJUST HOT WATER TEMPERATURE
Slayer Steam X features a blending valve that draws water from the
steam tank and main cold water line simultaneously. Custom water
temperatures are configured with the blending valve. Adjust the hot
water temperature with the following steps.
REQUIRED TOOLS
29
SLAYER STEAM X USER MANUAL V1.1 | SEPTEMBER 2019
