HAT700 SERIES ATS CONTROLLER USER MANUAL
HAT700 Series ATS Controller 2018-12-13 Version 1.5 Page 13 of 51
7.2 STATUS DESCRIPTION
7.2.1. S1 VOLTAGE STATUS
No.
Item
Description
1
S1 Available
S1 Normal Delay
2
S1 Unavailable
S1 Abnormal Delay
3
S1 Available
Power supply voltage is within the setting range.
4
S1 Blackout
Voltage is 0.
5
S1 Over Volt
Voltage is higher than the set value.
6
S1 Under Volt
Voltage has fallen below the set value.
7
S1 Over Freq
Frequency is higher than the set value.
8
S1 Under Freq
Frequency has fallen below the set value.
9
S1 Loss of Phase
Loss of any phase of A, B and C.
10
S1 Phase Seq Wrong
A-B-C phase sequence is wrong.
7.2.2. S2 VOLTAGE STATUS
No.
Item
Description
1
S2 Available
S2 Normal Delay
2
S2 Unavailable
S2 Abnormal Delay
3
S2 Available
Power supply voltage is within the setting range.
4
S2 Blackout
Voltage is 0.
5
S2 Over Volt
Voltage is higher than the set value.
6
S2 Under Volt
Voltage has fallen below the set value.
7
S2 Over Freq
Frequency is higher than the set value.
8
S2 Under Freq
Frequency has fallen below the set value.
9
S2 Loss of Phase
Loss of any phase of A, B and C.
10
S2 Phase Seq Wrong
A-B-C phase sequence is wrong.
7.2.3. GENSET STATUS
No.
Item
Description
1
Genset Start Delay
Delay time before genset start
2
Genset Return Delay
Delay time before genset stop
3
Scheduled Not Work
When scheduled not run is active, its duration time will be
displayed.
4
Scheduled Work
When scheduled run is active, its duration time will be displayed.
5
Gen1 Cycle Run
S1 cycle run countdown will be terminated when cycle start is
active.
6
Gen2 Cycle Run
S2 cycle run countdown will be terminated when cycle start is
active.
7
S1 Genset Working
Active when system type is “S1 Gens S2 Gens”.
8
S2 Genset Working
Active when system type is “S1 Gens S2 Gens”.
9
Genset Working
Genset start signal output.
10
Genset Standby
There is no start genset signal output.
