HAT700 SERIES ATS CONTROLLER USER MANUAL
HAT700 Series ATS Controller 2018-12-13 Version 1.5 Page 7 of 51
4 SPECIFICATION
Items
Contents
Operating Voltage
1. DC 8.0V~35.0V, continuous power supply.
2. AC90V~280V during AC power supply L1N1/L2N2 (HAT700B/HAT700BI
/HAT700S).
Power Consumption
<5W (Standby mode: ≤2W)
AC Voltage Input
AC system
HAT700/HAT700I
HAT700B/HAT700BI/
HAT700S
3P4W (L-L)
(80~625)V
(80~480)V
3P3W (L-L)
(80~625)V
(80~625)V
1P2W (L-N)
(50~360)V
(50~280)V
2P3W (A-B)
(80~625)V
(80~480)V
Rated Frequency
50/60Hz
Close Relay Output
16A AC250V Volts free output
Auxiliary Relay Output
16A/7A AC250V Volts free output
Digital Input
GND (B-) connect is active.
Communication
RS485 isolated interface, MODBUS Protocol
Case Dimensions
197mmx152mmx47mm
Panel Cutout
186mmx141mm
Working Conditions
Temperature: (-25~+70)°C;
Relative Humidity: (20~93)%RH
Storage Condition
Temperature: (-25~+70)°C
Protection Level
IP55: when water proof gasket ring inserted between panel and housing.
Insulation Strength
Apply AC2.2kV voltage between high voltage terminal and low voltage
terminal;
The leakage current is not more than 3.5mA within 1min.
Weight
HAT700/HAT700I: 0.7kg
HAT700B/HAT700BI/HAT700S: 0.8kg
