HAT700 SERIES ATS CONTROLLER USER MANUAL
HAT700 Series ATS Controller 2018-12-13 Version 1.5 Page 29 of 51
No.
Item
Description
).
24
Sync Inhibit
Sync transfer function is deactivated.
25
Scheduler Inhibit
Schedule Start and Schedule Not Start function are deactivated.
26
Simulate S1 OK
Simulate S1 voltage is normal; the S1 voltage abnormal delay is
deactivated.
27
Simulate S2 OK
Simulate S2 voltage is normal; the S2 voltage abnormal delay is
deactivated.
28
Reserved
29
Reserved
9.3.2 OUTPUT PORTS FUNCTION
No.
Items
Description
0
Not Used
Invalid
1
Custom Period 1
2
Custom Period 2
3
Custom Period 3
4
Custom Period 4
5
Custom Period 5
6
Custom Period 6
7
Reserved
8
Reserved
9
Reserved
10
Reserved
11
Common Alarm
It includes fault alarm and warn alarm.
12
Common Fault Alarm
It includes Transition Fault alarm and Over Current alarm.
13
Common Warn Alarm
It includes S1 Phase Sequence Wrong alarm, S2 Phase Sequence
Wrong alarm, Over Current and Forced Open alarm.
14
Transition Fault
It includes S1 Fail to Close alarm, S1 Fail to Open alarm, S2 Fail to
Close alarm, S2 Fail to Open alarm,.
15
Audible Alarm
Action when common alarm occurs. Can be connected annunciator
externally. When “alarm mute” input is active or 60s delay has
expired, it can remove the alarm.
16
Reserved
17
Genset Start Delay
Output when start signal is initiated.
18
Genset Stop Delay
Output when stop signal is initiated.
19
Elevator Control
Output before the load disconnect or switch transfer. Used for
control the running elevator stop at the nearest floor until the switch
transfer is terminated.
20
Reserved
21
Reserved
22
Reserved
23
S1 Available
Output when S1 power is normal.
24
S1 Unavailable
Output when S1 power is abnormal.
25
S2 Available
Output when S2 power is normal.
