9 PARAMETERS CONFIGURATION
9.1 ILLUSTRATION
In the main interface, press key, choose Configuration and press again to enter into
password confirmation interface. If password is correct, enter into parameter setting interface, otherwise,
exit to main interface directly. Factory default password is 01234. In parameters configuration interface,
pressing key to return the prior menu.
9.2 PARAMETERS TABLE
Parameters Item Table
No.
Item
Range
Default
Description
AC System
1
S1 Available Delay
(0-3600) s
10
The delay from S1 voltage abnormal to
normal.
2
S1 Unavailable Delay
(0-3600)s
5
The delay from S1 voltage normal to
abnormal.
3
S2 Available Delay
(0-3600)s
10
The delay from S2 voltage abnormal to
normal.
4
S2 Unavailable Delay
(0-3600)s
5
The delay from S2 voltage normal to
abnormal.
5
Master-Slave Set
(0-2)
0
0: S1 Master
1: S2 Master
2: No Master
6
System Type Set
(0-3)
0
0: S1 Mains S2 Gen
1: S1 Gen S2 Mains
2: S1 Mains S2 Mains
3: S1 Gen S2 Gen
7
AC System
(0-3)
0
0: 3-Phase,4-Wire
1: 3-Phase,3-Wire
2: 2-Phase,3-Wire
3: Single Phase,2-Wire
8
PT Fitted
(0-1)
0
0: Disable ; 1: Enable
9
PT Primary
(30-30000)V
100
Primary voltage of voltage transformer
10
PT Secondary
(30-1000)V
100
Secondary voltage of voltage transformer
11
Rated Voltage
(0-30000)V
220
Rated voltage of AC system
12
Over Volt
(0-1)
1
0: Disable ; 1: Enable
13
Over Volt Set Value
(0-200)%
120
Upper limit value of voltage; it is abnormal if
the value has exceeded the set value.
14
Over Voltage Return
(0-200)%
115
Upper limit return value of voltage; it is
normal only when the value has fallen below
the set value.
15
Under voltage
(0-1)
1
0: Disable ; 1: Enable
16
Under Voltage Set
Value
(0-200)%
80
Lower limit value of voltage; it is abnormal if
the value has fallen below the set value.
