8 START/STOP OPERATION
8.1 MANUAL START/STOP
8.1.1. PANEL START/STOP
In the main screen, press key will enter into manual start operation interface.
1.Return
2.Stop Genset
3.Start Genset
Press Up/Down key to choose parameters (the current line was
highlighted with black) and then press Confirm key to confirm.
Genset Stop：Disconnect the start signal, i.e. stop the running genset.
Genset Start：Output the start signal, i.e. start the genset.
When system is “S1 Gen S2 Gen”, manual start/stop menu interface is as follows:
1.Return
2.S1 Genset Stop
3.S1 Genset Start
4.S2 Genset Stop
5.S2 Genset Start
Press Up/Down key to choose parameters (the current line was
highlighted with black) and then press Confirm key to confirm.
S1 Genset Stop：Disconnect the S1 start signal, i.e. stop the running S1 genset.
S1 Genset Start：Output the S1 start signal, i.e. start the S1 genset.
S2 Genset Stop：Disconnect the S2 start signal, i.e. stop the running S2 genset.
S2 Genset Start：Output the S2 start signal, i.e. start the S2 genset.
8.1.2. REMOTE START/STOP
Send remote start/stop signals using MODBUS protocol via RS485 port.
Remote Stop：Disconnect the start signal, i.e. stop the running genset.
Remote Start：Output the start signal, i.e. start the genset.
8.2 AUTO START/STOP
8.2.1 INPUT PORT START/STOP OPERATION
Set input port as “Remote Start On Load” or “Remote Start Off Load”, both could not be set
simultaneously.
Remote Start on Load：When the input is active, genset close relay will active after genset is normal;
when the input inactive, genset will stop automatically.
Remote Start off Load：When the input is active, mains close relay will active after mains is normal;
genset close relay will active when the mains is abnormal while genset is normal; when the input inactive,
genset will stop automatically.
