HGM400 Series Genset Controller ISSUE 2015-05-27 Version 1.6 Page 16 of 44
5.2 SHUTDOWN ALARM
When controller detects shutdown alarm, it will send signal to open breaker and shuts
down generator. The alarm information will be displayed on LCD.
Shutdown alarms as following:
No
Items
Description
1
Emergency
Shutdown
When the controller detects that the emergency shutdown
signal, it will initiate a shutdown alarm and the corresponding
alarm information will be displayed on LCD.
2
High
Temperature
When controller detects that the water/cylinder temperature
has exceeded the pre-set value, it will initiate a shutdown
alarm and the corresponding alarm information will be
displayed on LCD.
3
Low Oil
Pressure
When the controller detects that the oil pressure has fallen
below the pre-set value, it will initiate a shutdown alarm and
the corresponding alarm information will be displayed on
LCD.
4
Over Speed
When the controller detects that the generator speed has
exceeded the pre-set value, it will initiate a shutdown alarm
and the corresponding alarm information will be displayed on

Smartgen HGM400 Series Specifications

General

AC Frequency	50/60Hz
Operating Temperature	-25°C to +70°C
Storage Temperature	-40°C to +85°C
Battery Voltage Detection	Yes
Engine Start/Stop Control	Yes
Alarm Output	Yes
Remote Start/Stop	Yes
Display	LCD
DC Supply/Input Voltage	8-35VDC
Humidity	≤95% RH (non-condensing)
Communication Interface	RS485
