HGM400 Series Genset Controller User Manual
HGM400 Series Genset Controller ISSUE 2015-05-27 Version 1.6 Page 31 of 44
7.2 PROGRAMMABLE OUTPUT 1-5 (TABLE 2)
No
Items
Description
0
Not Used
Output port is deactivated when “Not Used” is selected.
1
Common Alarm
Include all shutdown alarms and warning alarms. When
there is warning alarm only, it is not self-lock; when a
shutdown alarm occurs, it is self-lock until the alarm is
reset.
2
Energized to Stop
Suitable for genset with electromagnet and will active
after “stop idle delay”. It is deactivated when the “ETS
Solenoid delay” expires.
3
Idle Control
Used for engine which has idles. Close before starting
and open in warming up delay; Close during stop idle
delay and open when stop is completed.
4
Preheat Control
Close before starting and open before power up;
5
Close Generator
When close time is 0, it’s continuous output.
6
Mains Closed
When close time is 0, it’s continuous output.
(HGM410 without)
7
Open ATS
When close time is 0, it’s disabled.
8
Raise Speed
Close when the generator enters into Warming Up
delay (close time: warming up delay) while open when
Aux.
9
Drop Speed
Close when the generator enters into Stop Idle delay/
Energized to Stop delay (close time: Stop Idle delay)
while open when Aux.
10
Generator Run
Action when genset is normal running while
deactivated when engine speed is lower than the
“crank disconnect speed”.
11
Fuel Pump Control
Close when fuel level is lower than the “Fuel Pump On”
value or when low fuel level warning input is active;
Open when fuel level is higher than the “Fuel Pump
Off” and low fuel level warning input is deactivated;
12
High Speed Control
Close when the generator enters into Warming Up
delay while open after cooling delay.
13
In Auto Mode
The controller is in automatic mode.
14
Fuel Relay Output
To control fuel relay output.
15
Generator Excite
Output in start period. If there is no generator
frequency during safety running, output for 2 seconds.
16
Air Cooler Output
Control air cooler to start\stop according to cooler
temperature.
17
Reserved
