HGM400 Series Genset Controller User Manual
HGM400 Series Genset Controller ISSUE 2015-05-27 Version 1.6 Page 23 of 44
7.1 PARAMETER CONTENTS AND RANGE (TABLE 1)
No
Items
Range
Default
Description
1
Mains Normal
Delay
(0-3600)s
10
The time from mains abnormal to
normal or from normal to
abnormal; suitable for ATS
(automatic transfer switch).
2
Mains Abnormal
Delay
(0-3600)s
5
3
Mains Under
Voltage
(30-620)V
184
When mains voltage has fallen
below the set value, Mains Under
Voltage is active. When set the
value as 30V, the controller does
not detect under voltage signal.
Back lash: 10V
4
Mains Over
Voltage
(30-620)V
276
When mains voltage has
exceeded the set value, Mains
Over Voltage is active. When set
the value as 620V, the controller
does not detect over voltage
signal. Back lash: 10V
5
Transfer Rest
Delay
(0-99.9)s
1.0
Interval time from mains switch
off to generator switch on; or
from generator switch off to
mains switch on.
6
Start Delay
(0-3600)s
1
Time from mains abnormal or
remote start signal is active to
start genset.
7
Stop Delay
(0-3600)s
1
Time from mains normal or
remote start signal is deactivated
to genset stop.
8
Start Attempts
(1-10)times
3
Maximum crank times of crank
attempts. When reach this
number, controller will send start
failure signal.
9
Preheat Time
(0-300)s
0
Power-on time of heater plug
before starter is powered up.
10
Cranking Time
(3-60)s
8
Power-on time of starter
11
Crank Rest Time
(3-60)s
10
The waiting time before second
power up when engine start fail.
