HGM400 Series Genset Controller User Manual
HGM400 Series Genset Controller ISSUE 2015-05-27 Version 1.6 Page 36 of 44
8 PARAMETERS SETTING
Start the controller, then press to enter into the parameters setting menu, see fig 1
below:
Parameters Setting
When entering password interface, inputting “1234” can set part of the parameter
items in Table 1 while “0318” can set all the items. If there is need to set more
parameters (e.g. voltage calibration; current calibration), please contact the factory.
NOTES:
1. For HGM410, there are no items from 1 to 5 in Table 1; there are no mains items in
auxiliary output 1-5.
2. Please change the controller parameters when generator is in standby mode only
(e. g. Crank disconnect conditions selection, auxiliary input, auxiliary output,
various delay), otherwise, shutdown and other abnormal conditions may occurs.
3. Over voltage set value must be higher than under voltage set value, otherwise over
voltage and under voltage condition may occur simultaneously.
4. Over speed set value must be higher than under speed set value, otherwise over
speed and under speed condition may occur simultaneously.
5. Please set the generator frequency value as low as possible when cranking, in
order to make the starter be separated quickly as soon as possible.
6. Auxiliary input 1~4 could not be set as same items; otherwise, there are abnormal
functions. However, the auxiliary output 1~5 can be set as same items.
7. If need to shut down after cooling, please set any auxiliary input as “High
Temperature Stop Input”, then connect this input port to GND.
Information
LCD will display software version, issue date of the controller.
Note: In this interface, press will display the auxiliary inputs and outputs
status.
Language
Chinese, English, Spanish, Turkish and Russian interface can be selected.
Mode Select
The controller can be set as Test Mode, Manual Mode, Auto Mode or Stop Mode.
Note: Pressing key at any time will quit the setting and return to the
1 Set Parameters
2 Information
3 Language
4 Mode Select
To Next Page
