Smartgen HGM6510 User Manual

HGM6510 GENSET PARALLEL UNIT
HGM6510 Genset Parallel Unit
ISSUE 2013-07-15
Version 1.7
Page 23 of 52
On initiation of the trip condition the controller will de-energize the „Close Generator‟
Output to remove the load from the generator. Once this has occurred the controller will
start the Cooling delay and allow the engine to cool before shutting down the engine.
No
Type
Range
Description
27
Earth Fault
Current
Always active
If “earth fault” detection is enabled, when the
controller detects a generator earth fault
current has exceeded the pre-set value and
the action select “Shutdown”, it will initiate a
shutdown alarm and the corresponding
alarm information will be displayed on LCD.
6.3 TRIP AND STOP ALARMS
No
Type
Range
Description
1
Gen Over
Current
Always active
When the controller detects that the genset
current has exceeded the pre-set value, it
will initiate a trip and stop alarm and the
corresponding alarm information will be
displayed on LCD. *1
2
Reverse
Power
Always active
When the controller detects that the reverse
power value has exceeded the pre-set value,
it will initiate a trip and stop alarm and the
corresponding alarm information will be
displayed on LCD.
3
Loss Of
Excitation
Always active
When the controller detects that the genset
negative reactive power has exceeded the
pre-set value, it will initiate a trip and stop
alarm and the corresponding alarm
information will be displayed on LCD.
4
Negative
Sequence
Current
After generator
breaker is closed
When the controller detects an imbalance in
the load current above a pre-set level, it will
initiate a trip and stop alarm and the
corresponding alarm information will be
displayed on LCD.
5
Auxiliary
Inputs 1-9
User-defined
When the controller detects that the auxiliary
input 1-9 trip alarm signals, it will initiate a
trip and stop alarm and the corresponding
alarm information will be displayed on LCD.
6
MSC Error
When parallel
operation is
enabled
When the controller cannot detect other
controller on the MSC link, it will initiate a trip
and stop alarm and the corresponding alarm
information will be displayed on LCD.
7
MSC Too Few
Sets
Always active
If the module detects fewer modules on the
MSC link than the minimum number
configured in the unit, it will initiate a trip and
stop alarm and the corresponding alarm
information will be displayed on LCD.
