Smartgen HGM6510 User Manual

HGM6510 GENSET PARALLEL UNIT
HGM6510 Genset Parallel Unit
ISSUE 2013-07-15
Version 1.7
Page 10 of 52
3 SPECIFICATION
Parameter
Details
Working Voltage
DC8. 0V to 35. 0V, Continuous Power Supply.
Overall Consumption
<3W (Standby mode: ≤2W)
Alternator Voltage Input:
3 Phase 4 Wire
3 Phase 3 Wire
Single Phase 2 Wire
2 Phase 3 Wire
AC15V - AC360V (ph-N)
AC30V - AC600V (ph-ph)
AC15V - AC360V (ph-N)
AC15V - AC360V (ph-N)
True RMS Accuracy
1%
Alternator Frequency
50Hz/60Hz
Speed Sensor Voltage
1. 0 V to 24 V (RMS)
Speed Sensor Frequency
Maximum 10,000 Hz
Start Relay Output
16A DC28V power supply output
Fuel Relay Output
16A DC28V power supply output
Configurable Relay Output 1
16A DC28V power supply output
Configurable Relay Output 2
16A DC28V power supply output
Configurable Relay Output 3
16A DC28V power supply output
Configurable Relay Output 4
16A AC250V passive output
Configurable Relay Output 5
16A AC250V passive output
RS485 Interface
1500V Isolation;
Maximum transmission distance: 1.2 kilometers;
Baud rate:9600;
Stop bits: 1 bit;
Parity: No.
Terminal matched resistance:120 Ω
RS232 Interface
Non-isolated
Maximum transmission distance: 15 meters;
Baud rate:9600;
Stop bits: 1 bit;
Parity: No.
MSC CAN Interface
1500V Isolation;
Maximum transmission distance:
190 meters: Baud rate:330K;
250 meters: Baud rate:250K;
500 meters: Baud rate:125K;
Terminal matched resistance:120 Ω
Case Dimensions
260mm x 182mm x 57mm
Panel Cutout
214mm x 160mm
CT Secondary Current
Rated 5A
Working Conditions
Temperature: (-25~+70)°C
Humidity: (20~93)% without condensation
