Smartgen HGM6510 User Manual

HGM6510 Genset Parallel Unit
ISSUE 2013-07-15
Version 1.7
Page 38 of 52
HGM6510 GENSET PARALLEL UNIT
NOTE: Do not prescribe the same function to configurable inputs 1-9 (except for “Not
Used” and “User-defined”), otherwise incorrect operation can occur.
8.2 CONFIGURABLE OUTPUT PORTS 1-5
All output ports have the same options, similar functions can be prescribed to several
output ports.
simultaneously activated to control the breaker
closed.
Used in case of transformer load to avoid over current
shutdown when the generator is closed.
37
Auto Mode Input
When the input is active, the controller is in auto mode
and other modes are disabled.
38
Disable Shutdown
When the input is active, all the shutdown alarms are
disabled.
39
Monitor Mode Input
When the input is active, LCD shows “monitor mode”;
genset start and stop are not controlled in this mode
and only genset parameters are monitored.
40
Power manager mode
When the input is active, LCD shows “power
management mode”; in this mode, the controller could
not start/stop the gen-set, it is only responsible for
synchronization, power sharing, schedule start/stop
and breaker opening/closing.
41
Reserved
No.
Type
Description
00
Output Not Used
01
Air Flap Relay
Action when over speed shutdown and emergence stop.
It also can close the air inflow to stop the engine as soon
as possible.
02
Audible Alarm
Action when warning, shutdown, trips. Can be connected
annunciator externally. When “alarm mute” input is
active, this output is disabled.
03
Battery High Volts
Action when battery over voltage warning alarm.
04
Battery Low Volts
Action when battery under voltage warning alarm.
05
Digital Input 7 Active
Action when input port 7 is active
06
Digital Input 8 Active
Action when input port 8 is active
07
Digital Input 9 Active
Action when input port 9 is active
08
Start Relay Output
Action when genset is cranking and disconnect when
crank successful.
09
Fuel Relay Output
Action when genset is starting and disconnect when stop
is completed.
010
Calling for Scheduled
On
Action when scheduled start is activated and gen-set is
running (Auto mode)
011
Charging Alternator
Failure
Action when generator charging failure warning alarm.
012
Close Generator
Control generator to take load. ( Continuous active)
