Smartgen HGM6510 User Manual

HGM6510 GENSET PARALLEL UNIT
HGM6510 Genset Parallel Unit
ISSUE 2013-07-15
Version 1.7
Page 7 of 52
2 PERFORMANCE AND CHARACTERISTICS
 2 application modes:
1) Multi-set parallel operation;
2) Single unit (constant power output) parallel with mains.
 32-bit ARM microprocessor, LCD display with backlight, optional languages interface,
push-button operation;
 Complete monitoring functions: almost all generator electric/non-electric parameters
are monitored, as follows:
Generator electric parameters:
3-phase phase voltage Ua, Ub, Uc Unit: V
3-phase line voltage Uab, Ubc, Uca Unit: V
3-phase current Ia, Ib, Ic Unit: A
Frequency F1 Unit: Hz
Split phase active power PA, PB, PC Unit: kW
Total phase active power P Unit: kW
Split phase reactive power RA, RB, RC Unit: kVar
Total phase reactive power P Unit: kVar
Split phase apparent power SA, SB, SC Unit: kVA
Total phase apparent power S Unit: KVA
Split phase power factor PF1, PF2, PF3
Average power factor APF
Total active energy Unit: kWh
Total reactive energy Unit: kVarh
Total apparent energy Unit: kVAh
3-phase voltage phase sequence and phase angle
Bus/mains electricity parameters:
3-phase phase Voltage Ua, Ub, Uc Unit: V
3-phase line Voltage Uab, Ubc, Uca Unit: V
Frequency F1 Unit: Hz
3-phase voltage phase sequence and phase angle
Synchronization parameters:
Voltage difference between generator and bus/mains
Phase angle difference between generator and bus/mains
Frequency difference between generator and bus/mains
